Condenser Fan Motor, 1/2 HP, 1140 rpm, 60Hz

' Condenser Fan Motor, Motor Design 3-Phase, Motor Enclosure Design Open Air-Over, 1/2 HP, RPM Range 1101-1200, Nameplate RPM 1140, Voltage 200-230/460, 56Y Frame, Number of Speeds 1, Overall Length 16-5/16 In., Shaft Length 6 In., Shaft Orientation Up, Features Auto Protector, Quick Connect Design, Reversible, Motor Shaft Rotation CW/CCW, Full Load Amps 2.8-2.6/1.3, Stud Motor Mounting Type, Thermal Protection Auto, Insulation Class B, Service Factor 1.0, Bearings Ball '

• Price For: Each Hz: 60 Motor Service Factor: 1.00 Motor Shaft Rotation: CW/CCW Motor Bearings: Ball Phase: 3 No. of Speeds: 1 Motor Sub Application: Condenser Fan Motor Application: HVAC/R Motor Enclosure Design: Open Air-Over Item: Condenser Fan Motor Motor Thermal Protection: Auto Motor Design: 3-Phase Duty: Continuous
• Standards: UL Recognized (E46412/E44549), CSA Certified (LR43341/LR4642) Voltage Compatibility: 200, 208, 230, 240, 460, 200-230, 200-230/440, 208-230/460, 220/460, 200-230/460, 230/460 Features: Auto Protector, Quick Connect Design, Reversible Frame: 56Y Voltage: 200-230/460 Ins. Class: B Shaft Length: 6" Motor Shaft Design: Flat Overall Length: 16-5/16" Motor Mounting Position: Vertical Shaft Up
• Nominal Efficiency: 74.0% Motor Mounting Type: Stud Nameplate RPM: 1140 Max. Ambient Temp.: 60 Degrees C HP: 1/2 Length Less Shaft: 10-5/16" Full Load Amps: 2.8-2.6/1.3 Shaft Dia.: 5/8" Body Dia.: 6-1/2" Country of Origin (subject to change): Mexico
